For examples please see analytical NUCLEODUR Sphinx RP, RP applications (preparative)
Storage temperature
RT
Scope of delivery
1x preparative HPLC column, instruction leaflet, certificate of analysis
Hazardous material
No
Method
HPLC, preparative
Brand
NUCLEODUR
Base material
NUCLEODUR - high purity silica
Phase
NUCLEODUR C18 HTec
USP listing
L1
Surface chemistry
High density octadecyl (C18, ODS) modification, base deactivated (BDS)
Mode
Reversed phase (RP)
Type
VP HPLC column (preparative)
Hardware
Stainless steel
Column length
150 mm
Column inner diameter
32 mm
Particle type
Fully porous particles (FPP)
Particle shape
Spherical
Particle size
5 µm
Eluent in HPLC column
Acetonitrile – water
Endcapped
Yes
Carbon content
18.0 %
pH stability
1.0–10.0
Pore size
110 Å
Specific surface according to BET
340 m²/g
Temperature stability (max)
60 °C
Pressure stability (max)
400 bar
Column volume
121 mL
DESCRIPTION
Due to high loadability and further characteristics like excellent stability these HPLC columns packed with high purity NUCLEODUR C18 HTec silica gel are the choice for up-scaling to preparative scale.
