Catalog No. METL52206443
Part No. 52206443
Supplier METTLER TOLEDO
O2 Sensor InPro6950iG/12/120
Net Price
Special offer
Availability

4 weeks

PROPERTIES
  • Cable Connector
    K8S
  • Connection
    Pg 13.5
  • Hazardous Area Approvals
    ATEX: Ex ia IIC T6 / T5 / T4 / T3 Ga / Gb, Ex ia IIIC T69 °C / T81 °C / T109 °C / T161 °C Da / Db. FM: IS Cl. I, II, III, Div 1, GR ABCDEFG / T6 *
  • Hygienic/Biocompatibility Approvals
    EHEDG, FDA/USP Class VI
  • ISM (Digital) or Analog
    ISM (Digital)
  • Measured Pressure Resistance
    0.2 bar – 9 bar
  • Measurement Parameter
    Gas-Phase Oxygen
  • Measurement range
    6 ppm - 50000ppm
  • Measuring Temp. Range
    32 °F – 104 °F (0 °C – 40 °C)
  • Model Family
    InPro6950iG
  • Operating Pressure (Bar)
    0.200 bar–9.000 bar
  • Operating Pressure (PSI)
    2.9 to 130 psi absolute
  • Primary Media/Application
    Chemical Processes Food/Beverage Production
  • Process Connection
    Pg 13.5
  • Sensor Length
    120 mm
  • Temp. Range
    32 °F – 104 °F (0 °C – 40 °C)
  • Wetted Materials
    316L Stainless Steel
DESCRIPTION
The InPro 6950iG/12/120 is an amperometric gas-phase oxygen sensor designed for trace oxygen measurement in CO2 recovery in breweries. This sensor uses Intelligent Sensor Management (ISM) diagnostics to reduce maintenance and downtime.Accurate Trace Oxygen Measurement The InPro 6950iG/12/120 provides an accuracy of ±5 ppm in CO2 recovery applications in breweries, where trace level accuracy is critical. Save Money with CO2 Recovery Using the InPro 6950iG/12/120 helps measure and capture CO2 from fermentation so you can reduce CO2 purchases for carbonation. Real-Time Sensor Performance Monitoring The InPro 6950iG/12/120 uses ISM technology to provide advanced analytics of sensor health, calibration needs, and remaining membrane lifetime.
