Catalog No. METL52206436
Part No. 52206436
Supplier METTLER TOLEDO
O2 Sen InPro6850iG/12/220/1613311
Net Price
Special offer
Availability

4 weeks

PROPERTIES
  • Cable Connector
    K8S
  • Connection
    Pg 13.5
  • Hazardous Area Approvals
    ATEX: Ex ia IIC T6 / T5 / T4 / T3 Ga / Gb, Ex ia IIIC T69 °C / T81 °C / T109 °C / T161 °C Da / Db. FM: IS Cl. I, II, III, Div 1, GR ABCDEFG / T6 *
  • Hygienic/Biocompatibility Approvals
    EHEDG, FDA/USP Class VI
  • Intelligent Sensor Management (ISM®)
    Yes
  • ISM (Digital) or Analog
    ISM (Digital)
  • Measured Pressure Resistance
    0.2 bar – 9 bar
  • Measurement Parameter
    Gas-Phase Oxygen
  • Measurement range
    301 ppm - 100% O2
  • Measuring Temp. Range
    32 °F – 158 °F (0 °C – 70 °C)
  • Model Family
    InPro6850iG
  • Operating Pressure (Bar)
    0.200 bar–9.000 bar
  • Operating Pressure (PSI)
    2.9 to 130 psi absolute
  • Primary Media/Application
    Chemical Processes Pharmaceutical/Life Science Production
  • Process Connection
    Pg 13.5
  • Sensor Length
    220 mm
  • Temp. Range
    32 °F – 158 °F (0 °C – 70 °C)
  • Wetted Materials
    C22 Hastelloy
DESCRIPTION
The InPro 6850iG/12/220/C22 is an amperometric gas-phase oxygen sensor that is suited to a wide measurement range in a broad choice of applications. This sensor uses Intelligent Sensor Management (ISM) diagnostics to reduce maintenance and downtime.In-Line Gas Phase O₂ Measurement The InPro 6850iG/12/220/C22 is designed to measure gas-phase oxygen in-line, in harsh environments and hazardous area applications. Signal Stability & Reduced Maintenance The 3-electrode system of the InPro 6850iG/12/220/C22 includes a platinum anode that increases signal stability and extends maintenance intervals. Real-Time Sensor Performance Monitoring The InPro 6850iG/12/220/C22 uses ISM technology to provide advanced diagnostics, including days until the membrane kit should be replaced.
