HACH6940600 - HACH - Instruments

: Catalog No. HACH6940600

Part No. 6940600
Supplier HACH Company

Solitax sc Filter Backwash Turbidity Sensor Package

Net Price

6362

Availability

6 weeks

PROPERTIES

Automatic Wiper

Yes
Cable Length

10 m (optional extension cables available)
Calibration Method

Turbidity: Formazin or STABLCAL Standard (at 800 NTU). Suspended Solids: Sample specific, based on gravimetric TSS analysis with a correction factor procedure.
Certifications

CE
Controller

Sensor only
Diameter Sensor

60 mm
Flow

Max. 3 m/s (the presence of air bubbles affects the measurement)
Length

200 mm
Maintenance Interval

1 h/month
Material

Optics Carrier and Sleeve: stainless steel 1.4571; Wiper Arm: stainless steel 1.4581; Wiper Rubber: silicone rubber (standard) Optional: FKM/FPM (LZX578); Wiper Shaft: stainless steel 1.4571
Max. cable length Sensor-to-Controller

100
Measuring Principle

Infrared Duo scattered light technique for color-independent turbidity measurement Turbidity in accordance with DIN EN ISO 7027 / TS equivalent DIN 38414
Model

Solitax ts-line sc
Mounting

Immersion Immersion
Operating Temperature Range

0 - 40 °C
Parameter

Suspended Solids, Turbidity
Pressure Range

< 6 bar
Repeatability

< 3 %
Response Time T90

1 - 300 s adjustable
Warranty

12 months
What's included?

Solitax ts-Line Turbidity Sensor, User Manual, Backwash Filter Mounting Kit

DESCRIPTION

This package is for filter backwash applications at drinking water facilities. It includes a Solitax ts-line turbidity sensor and mounting hardware kit. The SC200 digital controller must be ordered separately. The Solitax sc sensor measures real-time NTU values during the filter backwash process with a probe range of 0.001 to 4000 NTU. The mounting kit for the filter back wash application is designed to allow for probe placement directly in the filter trough or near the top of the bed for optimal measurement. The new hardware includes a handrail mount and quick release pole connections for an easy 30 minute installation. Please download the mounting instructions for more details. The Sensor connects directly to all Hach sc controllers for immediate use.PROGNOSYS is now available to provide confidence in your instrument readings. PROGNOSYS will monitor and display the reliability of instrument measurement values and identify when upcoming maintenance tasks are due in an easy-to-read color display.
