188 x 160 x 86 mm (7.4 x 6.3 x 3.4 inches) with mounting bracket
Enclosure Rating
IP66
Operating Temperature Range
-20 °C - 60 °C (-4 °F - 140 °F)
Power Supply
12 VDC, 100 mA, supplied by the controller
Storage Conditions
-40 °C - 70 °C (-40 °F - 158 °F)
Warranty
12 months
Weight
0.76 kg (1.68 lbs)
DESCRIPTION
The CDx440sc digital SC gateway powers the GSx440 Hydrogen Sulfide sensor, monitors its status, and collects measurement data to be sent to the SC controller every five seconds.
