LXV424.99.00200 - HACH - Instruments

: Catalog No. LXV424.99.00200

Part No. LXV424.99.00200
Supplier HACH Company

Solitax highline sc Turbidity and Suspended Solids Insertion Probe with Wiper, Stainless Steel

Net Price

4308

Availability

6 weeks

PROPERTIES

Automatic Wiper

Yes
Body Material

Stainless Steel
Cable Length

10 m (optional extension cables available)
Calibration Method

Turbidity: Formazin or STABLCAL Standard (at 800 NTU). Suspended Solids: Sample specific, based on gravimetric TSS analysis with a correction factor procedure.
Certifications

CE, MCERTS
Controller

Sensor only
Diameter Sensor

60 mm
Flow

Max. 3 m/s (the presence of air bubbles affects the measurement)
Length

315 mm
Maintenance Interval

1 h/month
Material

Optics carrier and sleeve: PVC black Wiper arm: stainless steel 1.4581Wiper rubber: silicone rubber (standard)Optional: FKM/FPM (LZX578) Wiper shaft: stainless steel 1.4571
Max. cable length Sensor-to-Controller

100
Measuring Principle

Infrared Duo scattered light technique for color-independent turbidity measurement Turbidity in accordance with DIN EN ISO 7027 / TS equivalent DIN 38414
Model

Solitax highline sc
Mounting

Insertion
Operating Temperature Range

0 - 40 °C
Parameter

High Range Suspended Solids, Turbidity
Pressure Range

Stainless steel insertion sensor: <6 bar or <60 m
Range

TSS-content: 0.001 - 500 g/L; 0.001 - 500,000 mg/L (the upper range is dependent on the sample property)Turbidity: 0.001 - 4000 NTU
Repeatability

TSS content: < 3 %Turbidity: < 1 %
Response Time T90

1 - 300 s adjustable
Special Notes

Installation note:Distance sensor-wall > 50 cm (Turbidity)
Warranty

12 months
Weight

Insertion stainless steel: 2.4 kg (5.29 lb.)
What's included?

Turbidity/Suspended Solids probe, user manual

DESCRIPTION

High-precision in pipe turbidity and suspended solids measurements in high concentrated sludges according to DIN EN ISO 7027 and DIN 38414The Solitax highline sc turbidity and suspended solids insertion probe provides high-precision results in clear to strongly turbid liquids as well as in high concentrated sludges. Since this probe is for in pipe use only an appropriate mounting assembly for insertion application is required. Turbidity measurement performance is certified to MCERTS regulation and the probe operates with a 90° measuring method according to DIN EN ISO 7027. The suspended solids measurement by a colour-independent method with an infrared duo scattered light photometer is in accordance with DIN 38414. A proven automatic wiper cleaning system allows sustained performance quality in drinking water as well as in waste water applications. The Solitax highline sc probe material is stainless steel and measurement data is displayed and processed with the help of a digital Hach SC200 or SC1000 controller.Furthermore, the Solitax highline sc turbidity immersion probe is compatible for Prognosys which is a predictive diagnostic system that allows you to be proactive in your maintenance, by alerting you to upcoming instrument issues. Know with confidence whether changes in your measurements are due to changes in your instrument or your water. Please contact Hach for further information. Request for a quote today!This instrument connects to Claros, Hach’s innovative Water Intelligence System, enabling you to seamlessly connect and manage instruments, data, and process – anywhere, anytime. The result is greater confidence in your data and improved efficiency in your operations. To unlock the full potential of Claros, insist on Claros Enabled instruments.
