DESCRIPTION
TissuQuartz™ filters, a Pall Life Sciences product, are suited for a broad range of air monitoring applications
Useful for high temperature and hot gas air monitoring applications.
Ideal for stack sampling and diesel emissions testing.
Tissuquartz Filters
Heat treated for reduction of trace organics and superior chemical purity.
High temperature use for analysis of acidic gases and stack sampling aerosols.
High flow rate and filtration efficiency.
Ultra-pure soft water processing to reduce residual ion content.
Specifications
Filter Media
Pure quartz, no binder
Diameter
25 - 142 mm and 8 x 10 in
Typical Thickness
432 µm (17 mils)
Typical Filter Weight
5.8 mg/cm2
Typical Water Flow Rate0.35 bar (35 kPa, 5 psi)
220 mL/min/cm2
Typical Air Flow Rate0.7 bar (70 kPa, 10 psi)
73 L/min/cm2
Maximum Operating Temperature - Air
1093°C(2000°F)
Typical Aerosol Retention**
99.90%
pH in Boiled Water Extract
6.5 - 7.5
