KVVLG1ZTH1 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. KVVLG1ZTH1

Part No. KVVLG1ZTH1
Supplier Merck KGaA

Opticap® Gamma Compatible XLT10 Durapore® 0.1 µm 1.5 in TC-5/8 in HB w/gauge port

Net Price

Special offer

Availability

4 weeks

PROPERTIES

Bacterial Endotoxins

A sample aqueous extraction contains less than 0.5 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) test.
Bacterial Retention

Samples were quantitatively retentive of a minimum Brevundimonas diminuta challenge concentration of 1 x 10⁷ CFU/cm² using ASTM® F838 methodology.
Cartridge Nominal Length

10 in. (25 cm)
Catalogue Number

KVVLG1ZTH1
Chemistry

Polyvinylidene Fluoride (PVDF)
Device Configuration

Capsule
Device Material

Gamma-stable polypropylene
Device Size

10 in.
Diameter

1-1/2 in.
European Pressure Equipment Directive

EMD Millipore Corporation® certifies that this product complies with the European Pressure Equipment Directive, 97/23/EC of 29 May 1997. This product has been classified under Article 3 § 3 of the Pressure Vessel Directive. It has been designed and manufactured in accordance with sound engineering practice to ensure safe use. In compliance with Article 3 § 3 of this Pressure Vessel Directive, this product does not bear the CE mark.
Good Manufacturing Practices

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Gravimetric Extractables

The extractables level was equal to or less than 25 mg per capsule after 24 hours in water at controlled room temperature.
Housing Material

Polypropylene (PP)
Indirect Food Additive

All component materials meet the FDA Indirect Food Additive requirements cited in 21 CFR 177-182.
Inlet Connection

Sanitary Flange
Inlet Connection Diameter

1-1/2 in.
Length

10 in. (25 cm)
Material Package

Double Easy-Open bag
Material Size

1
Maximum Differential Pressure, bar (psid)

Forward: 5.5 bar (80 psid) @ 25 °C; 1.7 bar (25 psid) @ 80 °C. Reverse: 2.8 bar (40 psid) @ 25 °C, intermittent
Maximum Inlet Pressure (psig)

80 psig
Maximum Inlet Pressure, bar (psi)

5.5 bar (80 psi) @ 25 °C; 2.8 bar (40 psi) @ 60 °C; 1.0 bar (15 psi) @ 80 °C
Maximum Inlet Temperature

25 °C
Media

Durapore®
Non-Fiber Releasing

This product was manufactured with a Durapore® membrane which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
Outlet Connection

Hose Barb
Outlet Connection Diameter

5/8 in.
Pore Size

0.1 µm
Seal Material

Silicone (SI)
Sterility

Gamma
Sterilization

3 autoclave cycles of 60 min @ 126 °C; capable of 45 kilogray (4.5 Megarad) gamma exposure; not in-line steam sterilizable
Support Material

Polyester
Trade Name

Opticap®
USP Bacterial Endotoxins

A sample aqueous extraction contains less than 0.5 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) test.
Vent Cap Material

Polypropylene (PP)
Wettability

Hydrophilic

DESCRIPTION

Genuine product
