P2C01MV05 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. P2C01MV05

Part No. P2C01MV05
Supplier Merck KGaA

Pellicon® 2 Cassette with Ultracel® 1000 kDa Membrane, V screen, 0.5 m²

Net Price

2115

Availability

4 weeks

PROPERTIES

Catalogue Number

P2C01MV05
Chemistry

Composite Regenerated Cellulose (CRC)
Device Configuration

Cassette
Device Material

Polypropylene and Polysulfone end cap
Filter Code

PLCXK
Filter Type

Ultrafiltration
Good Manufacturing Practices

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Gravimetric Extractables

The extractables level was equal to or less than 1500 mg/m² after a water flush.
Height

2.16 cm (0.85 in.)
Key Applications

Protein PurificationAnalytical Sample Prep
Length

20.6 cm (8.1 in)
Material Size

1
Maximum Operating Temperature

0 - 30°C
Maximum Transmembrane Pressure

Forward: 3.4 bar (50 psig) @ 30°C; Reverse: 0.3 bar (5 psig) maximum
Media

Ultracel®
Membrane Area

0.5 m²
NMWL

1000 kDa
pH Range

pH2 – pH13
Recirculation Rate

7 to 10 L/min/m²
Screen Material

Polypropylene (PP)
Screen Type

Type V screen (open channel)
Trade Name

Pellicon®
Width

17.8 cm (7.0 in.)
