Gamma Compatible Millipak®-100 Filter Unit 0.22 µm 3/4 in. TC/TC
Net Price
346
Availability
4 weeks
PROPERTIES
Bacterial Endotoxins
Aqueous extraction contains ≤0.5 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Bacterial Retention
Samples were quantitatively retentive of a minimum Brevundimonas diminuta challenge concentration of 1 x 10⁷ CFU/cm² using ASTM® F838 methodology.
Catalogue Number
MPGL10CF3
Chemistry
Polyvinylidene Fluoride (PVDF)
Device Configuration
Capsule
Device Material
Polycarbonate
Diameter
7.6 cm (3.0 in.)
Filtration Area
500 cm²
Flow Rate
11 L/min @ 2.8 bar ΔP
Good Manufacturing Practices
These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Gravimetric Extractables
The extractables level was equal to or less than 2.5 mg per device after 24 hours in water at controlled room temperature.
Inlet Connection
Sanitary Flange
Inlet Connection Diameter
3/4 in.
Length
13 cm (5.12 in.)
Material Package
Double Easy-Open bag
Material Size
3
Maximum Differential Pressure, bar (psid)
Forward: 4.1 bar (60 psid) @ 25 °C; 1.7 bar (25 psid) @ 80 °C; 0.35 bar (5 psid) @ 123 °C; Reverse: 0.7 bar (10 psid) @ 25 °C
Maximum Inlet Pressure, bar (psi)
5.2 bar (75 psi) @ 25 °C
Media
Durapore®
Non-Fiber Releasing
This product was manufactured with a Durapore® membrane which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
Outlet Connection
Sanitary Flange
Outlet Connection Diameter
3/4 in.
Oxidizable Substances
Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥200 mL
Pore Size
0.22 µm
Process Volume
50 L
Sterility
Other
Sterilization
3 autoclave cycles of 90 min @ 123°C; not in-line steam sterilizable
Support Material
Polycarbonate
Trade Name
Millipak®
USP Bacterial Endotoxins
A sample aqueous extraction contains less than 0.5 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) test.
