KWSCA02FF3 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. KWSCA02FF3

Part No. KWSCA02FF3
Supplier Merck KGaA

Opticap® XL2 Milligard® 1.2/0.5 µm 3/4 in. TC/TC

Net Price

301

Availability

4 weeks

PROPERTIES

Bacterial Endotoxins

Aqueous extraction contains ≤0.5 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Cartridge Nominal Length

2 in. (5 cm)
Catalogue Number

KWSCA02FF3
Chemistry

Mixed Cellulose Esters (MCE)
Device Configuration

Capsule
Device Material

Polypropylene
Device Size

2 in.
Diameter

12.5 cm (4.9 in.)
European Pressure Equipment Directive

EMD Millipore Corporation® certifies that this product complies with the European Pressure Equipment Directive, 97/23/EC of 29 May 1997. This product has been classified under Article 3 § 3 of the Pressure Vessel Directive. It has been designed and manufactured in accordance with sound engineering practice to ensure safe use. In compliance with Article 3 § 3 of this Pressure Vessel Directive, this product does not bear the CE mark.
Filter Grade

Standard Milligard® Media
Filtration Area

0.07 m²
Format

Double Layer
Good Manufacturing Practices

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Gravimetric Extractables

The extractables level was equal to or less than 15 mg per capsule after 24 hours in water at controlled room temperature.
Housing Material

Polypropylene (PP)
Indirect Food Additive

All component materials meet the FDA Indirect Food Additive requirements cited in 21 CFR 177-182.
Inlet Connection

Sanitary Flange
Inlet Connection Diameter

3/4 in.
Inlet to Outlet Width

14.2 cm (5.6 in.)
Length

2 in. (5 cm)
Material Package

Double Easy-Open bag
Material Size

3
Maximum Differential Pressure, bar (psid)

3.5 bar (50 psid) @ 25 °C
Maximum Inlet Pressure (psig)

80 psig
Maximum Inlet Pressure, bar (psi)

5.5 bar (80 psi) @ 23 °C; 2.75 bar (40 psi) @ 60 °C; 1.0 bar (15 psi) @ 80 °C
Maximum Inlet Temperature

25 °C
Media

Housing Material
Nominal Pore Size

1.2 / 0.5 µm
Non-Fiber Releasing

This product was manufactured with a media combination which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
Outlet Connection

Sanitary Flange
Outlet Connection Diameter

3/4 in.
Oxidizable Substances

Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥1 L
Pore Size

1.2 / 0.5 µm
Seal Material

Silicone (SI)
Sterilization

3 autoclave cycles of 30 min @ 121 °C; not in-line steam sterilizable
Support Material

Polyester
Trade Name

Opticap®
USP Bacterial Endotoxins

A sample aqueous extraction contains less than 0.5 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) test.
Vent Cap Material

Polypropylene (PP)
Width

14.2 cm (5.6 in.)

DESCRIPTION

Genuine product
