D010F4P01 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. D010F4P01

Part No. D010F4P01
Supplier Merck KGaA

Clarigard Cartridge Filter 40 in. 1.0 µm Code F PE

Net Price

172

Availability

4 weeks

PROPERTIES

Bacterial Endotoxins

Aqueous extraction contains ≤0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Cartridge Code

Code F double open end w/flat gaskets
Cartridge Nominal Length

40 in. (100 cm)
Catalogue Number

D010F4P01
Chemistry

Polypropylene (PP)
Device Configuration

Cartridge
Device Material

Polypropylene
Diameter

6.7 cm (2.6 in.)
Gravimetric Extractables

≤40 mg after 24-h soak in water
Length

40 in. (100 cm)
Material Size

1
Maximum Differential Pressure, bar (psid)

4.8 bar (70 psid) @ 25 °C
Maximum Inlet Pressure, bar (psi)

4.8 bar (70 psi) @ 25 °C
Nominal Pore Size

1.0 µm
Oxidizable Substances

Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥12 L
Pore Size

1.0 µm
Seal Material

Polyethylene (PE)
Sterilization

10 autoclave cycles or SIP @ 126 °C for 30 min
Trade Name

Clarigard®
Wettability

Hydrophilic
