SV03A47FF3 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. SV03A47FF3

Part No. SV03A47FF3
Supplier Merck KGaA

Optiscale® Durapore® Multimedia 0.2/0.22 µm 3/4 in. TC/TC

Net Price

131

Availability

4 weeks

PROPERTIES

Bacterial Endotoxins

Aqueous extraction contains ≤0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Catalogue Number

SV03A47FF3
Chemistry

Mixed Cellulose Esters (MCE)Polyvinylidene Fluoride (PVDF)
Device Configuration

Capsule
Device Material

Polycarbonate
Diameter

6.9 cm (2.7 in.)
Filtration Area

17.7 cm²
Good Manufacturing Practices

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Indirect Food Additive

All component materials meet the FDA Indirect Food Additive requirements cited in 21 CFR 177-182.
Inlet Connection

Sanitary Flange
Inlet Connection Diameter

3/4 in.
Length

91.4 mm
Material Size

3
Maximum Differential Pressure, bar (psid)

5.5 bar (80 psid) @ 25 °C
Maximum Inlet Pressure (psig)

80 psig
Maximum Inlet Pressure, bar (psi)

5.5 bar (80 psi) @ 25 °C
Maximum Inlet Temperature

25 °C
Media

Multimedia Durapore®
Outlet Connection

Sanitary Flange
Outlet Connection Diameter

3/4 in.
Oxidizable Substances

Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥100 mL
Pore Size

0.2 µm
Process Volume

100 mL
Seal Material

Fluoroelastomer (FKM)
Sterility

Other
Sterilization

3 autoclave cycles of 60 min @ 123 °C
Support Material

Polypropylene
Trade Name

OptiScale®
Vent Cap Material

Polyvinylidene fluoride (PVDF)
Volume

100 mL
Wettability

Hydrophilic
