A sample aqueous extraction contains less than 0.5 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) test.
Bacterial Retention
Samples were quantitatively retentive of a minimum Brevundimonas diminuta challenge concentration of 1 x 10⁷ CFU/cm² using ASTM® F838 methodology.
Catalogue Number
MPGL04GK2
Chemistry
Polyvinylidene Fluoride (PVDF)
Device Configuration
Gamma Gold Capsule
Diameter
1/4 in.
Good Manufacturing Practices
These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Gravimetric Extractables
The extractables level was equal to or less than 1.5 mg per sterilized device after a 200 mL flush and 24 hours in water at controlled room temperature.
Inlet Connection
NPTM
Inlet Connection Diameter
1/4 in.
Material Size
2
Maximum Differential Pressure, bar (psid)
Forward: 4.1 bar @ 25 °C; 1.7 bar @ 80 °C; 0.35 bar @ 123 °C; Reverse: 0.7 bar @ 25 °C
Maximum Inlet Pressure, bar (psi)
5.2 bar @ 25 °C
Media
Durapore®
Non-Fiber Releasing
This product was manufactured with a Durapore® membrane which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
Outlet Connection
Stepped Hose Barb with Bell
Outlet Connection Diameter
1/4 in.
Overview
This Millipak® filter delivers particulate- and bacteria-free water at the point of dispense (POD) of water purification systems. Millipak® membrane filters are made with Durapore® PVDF membranes to provide high flow rates and throughputs, low extractable, and broad chemical compatibility. It is gamma-irradiated for additional bacteria control. The filtered water can be used for laboratory work where bacteria control is crucial (cell culture, microbiology media preparation, etc.).
Pore Size
0.22 µm
Sterility
Sterile
Trade Name
Millipak®
USP Bacterial Endotoxins
A sample aqueous extraction contains less than 0.5 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) test.
Wettability
Hydrophilic
DESCRIPTION
• Sterile 0.22 µm membrane filter for particulate- and bacteria-free water at the point of dispense• Use with Alpha-Q, Milli-DI® and Milli-Q® Academic/Biocel/Element/Synthesis/Plus/Gradient systems
