Catalog No. METR6.00450.100
Part No. 6.00450.100
Supplier Metrohm AG
Combined Ag ring electrode
Net Price
Special offer
Availability

6~8 weeks

PROPERTIES
  • pH range
    0...14
  • Shaft material
    Glass
  • Measuring range (theoretical)
    -2000...2000
  • Measuring unit
    mV
  • Temperature range, long-term (°C)
    0...70
  • Temperature range, short-term (°C)
    0...70
  • Max. installation length (mm)
    125
  • SGJ sleeve
    flexible
  • Shaft diameter top (mm)
    12
  • Shaft diameter bottom (mm)
    6
  • Min. immersion depth (mm)
    15
  • Electrode plug-in head
    Metrohm plug-in head G
  • Indicator electrode type
    Ag
  • Indicator electrode shape
    Ring
DESCRIPTION
Combined silver ring electrode with fixed ground-joint diaphragm.This electrode is suitable for precipitation titrations when the pH value varies (titrant silver nitrate) of, e.g.: Chloride, bromide, iodideSulfidesHydrogen sulfideMercaptansCyanides The fixed ground-joint diaphragm is insensitive to contamination and the permanently fused-in silver ring is resistant to more highly concentrated acids and saline solutions.c(KNO3) = 1 mol/L is used as reference electrolyte and storage solution. Depending on the application, we recommend using an Ag ring electrode with a coating (AgBr, AgCl or Ag2S coating), which can be ordered accordingly.
