DESCRIPTION
BAC100B-785: Lab-grade fiberoptic Raman probe assembly; 105µm diameter 0.22NA fiber for 785 nm excitation 200µm diameter 0.22NA for Raman pickup, optical density >6; down to 150 cm-1. 304SS shaft has 0.371” (9.5 mm) diameter and 3” (76.2 mm) L. The 1.5 m fiber is terminated in SMA905 on the spectrometer end and FC/PC on the laser end. Adhesive sealed quartz window for non-contact sampling. 5.5 mm working distance. Maximum operating temperature is 80 degrees C. Not for immersive use.BAC100B-785
