LXV329.99.10002 - HACH - Instruments

: Catalog No. LXV329.99.10002

Part No. LXV329.99.10002
Supplier HACH Company

TSS TITANIUM2 sc Turbidity and Suspended Solids Immersion Probe, Titanium

Net Price

9146

Availability

6 weeks

PROPERTIES

Automatic Wiper

No
Cable Length

10 m (optional extension cables available)
Calibration Method

Turbidity (TRB): Factory calibratedSolids (TS): To be calibrated by customer on siteZero point: Permanently calibrated in the factory
Flow

Max. 3 m/s (the presence of air bubbles affects the measurement)
Length

Tank sensor: 330 mm
Maintenance Interval

1 h/month
Material

Gasket: FKM; Wiper: PA (GF), TPV
Measuring Principle

Combined multiple beam alternating light method with infrared diode system and beam focusingTurbidity: 2-channel 90° scattered light measurement in accordance with DIN/EN 27027/ISO 7027, wavelength = 860 nmSolids: Modified absorption measurement; eight-channel multiple-angle measurement, wavelength = 860 nm
Model

TSS Titanium sc
Operating Temperature Range

0 - 60 °C
Parameter

Turbidity, Suspended Solids
Pressure Range

10 bar or 100 m
Range

Turbidity (TRB): 0.001 - 9999 NTUSolids (TSS): 0.001 - 500 g/L
Repeatability

TSS content: < 4 %Turbidity: < 3 %
Response Time T90

1 - 300 s adjustable
Special Notes

Installation note:Distance sensor–wall > 50 cm (Turbidity)> 10 cm (TSS)
Warranty

12 months
Weight

approx. 1.6 kg
What's included?

Turbidity & Suspended Solids sensor, user manual

DESCRIPTION

Turbidity and suspended solids Immersion probe specially designed for use in aggressive fluids in the industrial sectorThe TSS Titanium2 sc is a digital process probe for the extremely accurate measurement of turbidity and suspended solids specially designed for use in aggressive fluids (e.g. organic and inorganic acids, lyes and chloride-containing solutions). This immersion probe is installed by tank-side mounting and can measure both on-line suspended solids and turbidity in one instrument. The two channel 90° scattered light turbidity method is in accordance with DIN EN ISO 7027. For the determination of suspended solids a scattered light measurement method at 120 ° is integrated. This eight channel measurement system, with an integrated bubble and temperature compensating software, enables the instrument to have a wide measuring range. The TSS Titanium2 sc probes are compatible with the Hach SC200 and SC1000 controller platform. Furthermore, they are made of titanium with a scratch resistant and easy to clean sapphire window design to withstand harsh environments.Please contact Hach for further information. Request for a quote today!
