Catalog No. K1200-S00
Part No. K1200-S00
Supplier HACH Company
Orbisphere K1200 LDO Oxygen sensor, 0 - 2000 ppb, 28 mm Orbisphere fitting
Net Price
Special offer
Availability

6 weeks

PROPERTIES
  • Certifications
    2004/108/EC - EN 61326-1
  • Communication Capabilities
    3 x 0/4-20 mA; RS485; Ethernet
  • Mounting
    28 mm Orbisphere fitting
  • Parameter
    Oxygen
  • Power Requirements (Voltage)
    100 - 230 VAC
  • Range
    0 - 2000 ppb dissolved O2 (DO)
  • Relays
    Measurement board: 3 measurement alarm relays (1A-30 VAC or 0.5A-50 VDC), configurable to send diagnostics information. Main board: 1 system alarm relay (1A-30 VAC or 0.5A-50 VDC).
  • Repeatability
    ± 0.4 ppb or 1 % whichever is greater
  • Sensors
    K1200 LDO
  • Storage Conditions
    -5 °C - 100 °C
  • Warranty
    12 months
  • What's included?
    K1200 Sensor only.Controller 510, sensor cable, flow-chamber or process connection must be ordered separately.
DESCRIPTION
The first maintenance-free optical oxygen sensor for nuclear power plants.The Hach Orbisphere K1200 sensor is a high accuracy Luminescent Dissolved Oxygen (LDO) sensor that has been optimized for measurements in water processes in the power and steam industry.Designed for mechanical robustness to extend service life and optimize total cost of ownership, the sensor, combined with the Orbisphere Controllers, offers a new way to monitor dissolved oxygen in power plants. Based on good engineering practice the Orbisphere K1200 LDO sensor is suitable for nuclear plant application.Maintenance and operating costs are significantly reduced due to the absence of membrane and electrolyte and sensor accuracy is unaffected by process changes such as flow changes.
