LXZ524.99.A0008 - HACH - Instruments

: Catalog No. LXZ524.99.A0008

Part No. LXZ524.99.A0008
Supplier HACH Company

Claros Connector w/ LAN; 1 year

Net Price

1334

Availability

6 weeks

PROPERTIES

Altitude

2000 m (6562 ft) maximum
Analog Output Functional Mode

Linear, PID
Communication Capabilities

Profibus DPV1 card
Compatible Instruments

Ammonium: Amtax sc, AN-ISE sc, A-ISE scNitrate: Nitratax sc, N-ISE sc, Nitratax clear/eco/plus scPhosphate: Phosphax sc, Phosphax sc LROrganics: Uvas scpH/ORP: pHD sc, 1200-S sc, 8362scConductivity: 3700sc, 3798-S sc, 3400scOzone: 9185scDissolved Oxygen: LDO 2 scChlorine: CL10sc, CL17sc, 9184scChlorine dioxide: 9187scSuspended Solids: Solitax sc, TSS scSludge Level: Sonatax scTurbidity: TU5300sc/TU5400sc, Ultraturb sc, SS7 sc
Compatible Network Technologies

GSM 3G/4G (e.g. AT&T, T-Mobile, Rogers, Vodafone etc.)CDMA (e.g. Verizon)
Compliance Certifications

CE approved (with all sensor types). Listed for use in general locations to UL and CSA safety standards by ETL (with all sensor types).Certain AC mains powered models are listed for use in general safety locations to UL and CSA safety standards by Underwriters Laboratories (with all sensor types).
Conduit Openings

½" NPT conduit
Dimensions

½ DIN - 144 x 144 x 192 mm (5.7 x 5.7 x 7.6 in.)
Display

None
Enclosure Rating

NEMA 4X/IP66 metal enclosure with a corrosion-resistant finish
Installation Category

Category II
Material Enclosures

Polycarbonate, aluminum (powder coated), stainless steel
Measurements

Two device digital SC connectors
Mounting

Wall, Pole, or Panel Mounting
Network Connectivity

LAN version: Two Ethernet connectors (10/100 Mbps), switch function, M12 female D-coding connector.Cellular version: SIM card holder (3G/4G).The type of connection is dependent on controller configuration.
Operating Temperature Range

LAN version: -20 - 60 °C (-4 - 140 °F)Cellular version: -20 - 55 °C (-4 - 131 °F)
Outputs

Five 4-20 mA analog outputs on each analog output module
Pollution Degree

2
Power Requirements (Voltage)

100 - 240 VAC
Protection Class

I, connected to protective earth
Relays

High voltage:Two relays (SPDT)Maximum switching voltage: 250 VACMaximum switching current: 5 A (resistive only load)Maximum switching power: 1250 VA, 125 W (resistive only load)Wire gauge: 0.75 to 2.5 mm2 (18 to 12 AWG)Low voltage:Four relays on each low voltage relay module
Storage Conditions

-20 - 70 °C (-4 - 158 °F), 0 - 95% relative humidity, non-condensing
USB Port

Used for data download and software upload. The controller records approximately 20,000 data points for each connected sensor.
Warranty

12 months
Weight

3.7 lb (controller only, w/o modules)
What's included?

LXV524.99.010A0 SC4200c Claros Connector with LAN + internal 3G/4G US AT&T, w/o plugLXZ524.99.00046 Remote service connector for SC200LZY472-01 USB Ethernet AdapterLZY990 LAN CableCLAROS-YRLY Claros Base Fee (1-yr)MSM-SENSOR-YRLY MSM Sensor Subscription (1-yr)MSM-SENSOR-YRLY MSM Sensor Subscription (1-yr)STARTUP TRAVEL Service Travel ChargeMSM-STARTUP Service Commissioning Charge

DESCRIPTION

Contains the equipment and Services needed to connect the SC200 or SC1000 to MSM for up to two Claros-enabled sensors.LXZ524.99.A0008 is a bundle KTO that includes additional items: CLAROS-YRLY, MSM-SENSOR-YRLY (Qty 2), STARTUP TRAVEL, and MSM-STARTUP will be added to the invoice. Total charge will remain unchanged.
