LXV524.99.00110 - HACH - Instruments

: Catalog No. LXV524.99.00110

Part No. LXV524.99.00110
Supplier HACH Company

SC4200c Controller, mA out, 1 digital Sensor, w/o plug

Net Price

Special offer

Availability

6 weeks

PROPERTIES

Altitude

2000 m (6562 ft) maximum
Analog Output Functional Mode

Linear, PID
Communication Capabilities

None
Compatible Instruments

Ammonium: Amtax sc, AN-ISE sc, A-ISE scNitrate: Nitratax sc, N-ISE sc, Nitratax clear/eco/plus scPhosphate: Phosphax sc, Phosphax sc LROrganics: Uvas scpH/ORP: pHD sc, 1200-S sc, 8362scConductivity: 3700sc, 3798-S sc, 3400scOzone: 9185scDissolved Oxygen: LDO 2 scChlorine: CL10sc, CL17sc, 9184scChlorine dioxide: 9187scSuspended Solids: Solitax sc, TSS scSludge Level: Sonatax scTurbidity: TU5300sc/TU5400sc, Ultraturb sc, SS7 sc
Compatible Network Technologies

GSM 3G/4G (e.g. AT&T, T-Mobile, Rogers, Vodafone etc.)CDMA (e.g. Verizon)
Compliance Certifications

CE approved (with all sensor types). Listed for use in general locations to UL and CSA safety standards by ETL (with all sensor types).Certain AC mains powered models are listed for use in general safety locations to UL and CSA safety standards by Underwriters Laboratories (with all sensor types).
Conduit Openings

½" NPT conduit
Dimensions

½ DIN - 144 x 144 x 192 mm (5.7 x 5.7 x 7.6 in.)
Display

None
Enclosure Rating

NEMA 4X/IP66 metal enclosure with a corrosion-resistant finish
Installation Category

Category II
Material Enclosures

Polycarbonate, aluminum (powder coated), stainless steel
Measurements

Two device digital SC connectors
Mounting

Wall, Pole, or Panel Mounting
Network Connectivity

LAN version: Two Ethernet connectors (10/100 Mbps), switch function, M12 female D-coding connector.Cellular version: SIM card holder (3G/4G).The type of connection is dependent on controller configuration.
Operating Temperature Range

LAN version: -20 - 60 °C (-4 - 140 °F)Cellular version: -20 - 55 °C (-4 - 131 °F)
Outputs

5x mA Output
Pollution Degree

2
Protection Class

I, connected to protective earth
Relays

High voltage:Two relays (SPDT)Maximum switching voltage: 250 VACMaximum switching current: 5 A (resistive only load)Maximum switching power: 1250 VA, 125 W (resistive only load)Wire gauge: 0.75 to 2.5 mm2 (18 to 12 AWG)Low voltage:Four relays on each low voltage relay module
Sensor Input #1

Digital
Sensor Input #2

None
Sensors

1 x Digital Sensor
Storage Conditions

-20 - 70 °C (-4 - 158 °F), 0 - 95% relative humidity, non-condensing
USB Port

Used for data download and software upload. The controller records approximately 20,000 data points for each connected sensor.
Warranty

12 months
Weight

3.7 lb (controller only, w/o modules)

DESCRIPTION

Hach's new SC4200c controller gives you total control of your wastewater process. The SC4200c enables communication for Mobile Sensor Management (MSM). Mobile Sensor Management provides clarity through easy access to crucial information, helping you manage your process and be proactive in your maintenance.This instrument connects to Claros, Hach’s innovative Water Intelligence System, enabling you to seamlessly connect and manage instruments, data, and process – anywhere, anytime. The result is greater confidence in your data and improved efficiency in your operations. To unlock the full potential of Claros, insist on Claros Enabled instruments.
