Catalog No. CYT28420107
Part No. 28420107
Supplier Cytiva
Polycap TF 36, 0.2
Net Price
99
Availability

4 weeks

PROPERTIES
  • Dimensions
    36 mm
  • Operating pressure max.
    4.1 bar (60 psi)
  • Inlet Connector
    Female national pipe thread (FNPT)
  • Outlet Connector
    Female national pipe thread (FNPT)
  • Housing
    Polypropylene (PP)
  • Flow Direction
    Supported bidirectionally. Certain applications may require orientation, i.e., vents. Reverse flow only for low pressure applications.
  • Sterilization
    May be autoclaved at 121°C for 20 minutes. Multiple autoclave cycles are possible. However, the responsibility for reuse is with the operator.\nThe device should be protected from cross contamination. An integrity test should be performed after autoclaving.Compatible with EtO sterilization.
  • Sealing
    Heat-fused
  • Support System
    Polypropylene (PP)
  • Pore Size
    0.2 µm
DESCRIPTION
Whatman Polycap TF capsule filters from Cytiva are made with durable, hydrophobic polytetrafluoroethylene (PTFE) membranes in a polyproplyene housing for use with organic solvents and chemically aggressive solutions. PTFE filter membrane is resistant to most solvents Available in 0.1, 0.2, 0.45, and 1.0 µm pore sizes 1.0 µm pore size capsules used for extended life and filtration of highly contaminated solutions Manufactured according to ISO9001:2008 QMS standards Autoclavable capsule filtration device if sterility is required Cytiva business offers a variety of Whatman Polycap filter options beyond PTFE filter membrane media. Browse the Whatman range to find the right capsule filter for your application. Whatman Polycap filter for aggressive solventsFiltration of organic solvents and aggressive solutions requires a durable membrane for filtration without sample contamination.Autoclavable Polycap TF capsule filters feature PTFE membranes with high chemical resistance. Common applications include venting, in-line filtration to sterilize* and remove particles from air/gas/liquid streams, filtration to ensure clean inert gases in vial filling lines, and isolation of exhaust from fermenters.Polycap TF filters support use in the electronics, pharmaceutical, and biopharmaceutical industries, because they are photoresistant and can be used to vent and perform in-line filtration for production systems in biological environments.Looking for a filter paper, membrane filter, or syringe filter? Let Cytiva help you find the optimal filter for your needs to ensure reliable analysis.*Refers to sterilization by filtration for small sample use which is an industry term for filters of pore size 0.2 um or smaller as referenced in guidance such as EPA Guidance for Industry Sterile Drug Products Produced by Aseptic Processing — Current Good Manufacturing Practice Section IX, Part B (September 2004).
