DESCRIPTION
ValuPrep™ syringe filters, a Pall Life Sciences product, are reliable, high-quality syringe filters for HPLC and UHPLC sample processing and clarification.
Syringe Filters.
Apply gentle pressure to begin filtration. (A gentle pressure helps assure maximum throughput.) CAUTION: As the
filter removes particulate, filtration will become more difficult (the syringe plunger will be harder to use) and pressure
will rapidly increase on the filter. Change filters when resistance becomes excessive. Failure to change filter may result
in membrane rupture, which results in particulate contaminating the filtrate. These filters are for single use only.
Specifications
Materials of Construction
Filter Media:
wwPTFE: wwPTFE membrane (hydrophilic polytetrafluoroethylene)
PTFE: Hydrophobic polytetrafluoroethylene membrane on a polypropylene support
Nylon: Hydrophilic nylon membrane
PVDF: Hydrophilic polyvinylidene fluoride membrane
Housings: Polypropylene
Pore Size
0.2 and 0.45 µm
Effective Filtration Area
25 mm: 2.8 cm2
Sample Volume
25 mm:
Inlet/Outlet Connections
Female Luer-Lok inlet/male luer outlet
Typical hold-up volume (with air purge)
25mm:
Maximum Operating Temperatures
wwPTFE and Nylon 55°C (131°F)
PTFE and PVDF 100°C (212°F)
Maximum Operating Pressure
PVDF: 3.4 bar (340 kPa, 50 psi)
Nylon: 6.2 bar (620 kPa, 90 psi)
wwPTFE and PTFE: 6.9 bar (690 kPa, 100 psi)
