Fluorodyne™ EX grade EDT filter, a Pall Life Sciences product, is a 0.1 micron rated, validated, highly retentive mycoplasma control filter to be used where the sterility assurance and economical filtration of growth media or other hard-to-filter fluids is paramount. A triple membrane layer construction contributes to outstanding throughput, high flow rates and the superior retention of bacteria and mycoplasma during the filtration of process fluids. The laid-over pleat modular cartridge pleating geometry in combination with a narrow core design allows for a high effective filtration area per filter element, resulting in, small foot-print filter systems with improved process efficiencies. AB style filters are disposable 125 mm (5 inch), 254 mm (10 inch), 508 mm (20 inch), 762 mm (30 inch) and 1016 mm (40 inch) modular element cartridges to be used with stainless steel housing assemblies. Fitted with 226 o-rings as standard suitable for medium to large scale manufacturing operations (100 L to >1000 L). These filters can be supplied encapsulated as the Kleenpak™ Nova capsule format. A validation package for Fluorodyne EX EDT Filters supports the assurance of safety within your process. Key Features and Benefits Retentive for B. diminuta as per ASTM838-05 Laid over pleat filter construction allows for high flow rates and smaller filtration systems Narrow core design for more area Asymmetric built-in prefilter for highest dirt-holding capacity Typically > 10 LRV Acholeplasma laidlawii and Mycoplasma orale removal High flow rates Low protein and preservative binding Low extractables Designed for autoclaving or SIP under wet or dry conditions 2D Matrix marking for electronic traceability * Quality Standards All Individual filter elements are integrity tested – test correlated to microbial retention Manufactured for use in conformance with cGMP ISO 9000 Certified Quality System Meets USP Biological Reactivity Test, in vivo, for Class VI-121°C Plastics Certificate of Test provided includes: Fabrication Integrity Bacterial Retention Materials of constructions Effluent quality for cleanliness, TOC and Water Conductivity, pH and Pyrogens * not currently included in 125 mmm (5 in.) filter cartridges
