DESCRIPTION
0.8 μm GN-4 Metricel™ membrane, a Pall Life Sciences product, has a low fiber background count. It is widely accepted for air monitoring of fibers, asbestos fibers, and metals.
Available unassembled for costeffective monitoring with a variety of membranes.
Leak proof and tamper proof. Banded cassettes ensure air-tight seal for critical applications
Materials of Construction
Filter Media: GN-4 Metricel membrane (mixed cellulose esters) with cellulose support pad
Housing: Carbon-filled polypropylene
Effective Filtration Area
3.85 cm2
Dimensions
Overall Length [Includes 5 cm (2 in.)
Extension: 7.9 cm (3.1 in.)
Diameter: 2.8 cm (1.1 in.)
Filter Size
25 mm
Inlet/Outlet Connections
Luer-type female inlet, female luer built-in hose adapter outlet
Operating Temperature
AmbientApplications
GN-4 Metricel membrane meets fiber count and background requirements to comply with NIOSH Methods 7400 and 7402.
Cassettes can be used to monitor respirable constituents such as silica, metal, and dusts.
