KGEPA3THH1 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. KGEPA3THH1

Part No. KGEPA3THH1
Supplier Merck KGaA

Opticap® XLT 30 Millipore Express® SHF Autoclavable 0.2 µm 5/8 in. HB

Net Price

898

Availability

4 weeks

PROPERTIES

Bacterial Endotoxins

Aqueous extraction contains ≤0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Bacterial Retention

Samples were quantitatively retentive of a minimum Brevundimonas diminuta challenge concentration of 1 x 10⁷ CFU/cm² using ASTM® F838 methodology.
Cartridge Nominal Length

30 in. (75 cm)
Catalogue Number

KGEPA3THH1
Chemistry

Polyethersulfone (PES)
Device Configuration

Capsule
Device Material

Polypropylene/Polysulfone
Device Size

30 in.
Diameter

10.7 cm (4.2 in.)
Filtration Area

1.62 m²
Good Manufacturing Practices

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Housing Material

Polypropylene (PP)
Indirect Food Additive

All component materials meet the FDA Indirect Food Additive requirements cited in 21 CFR 177-182.
Inlet Connection

Hose Barb
Inlet Connection Diameter

5/8 in.
Inlet to Outlet Width

19.8 cm (7.8 in.)
Length

30 in. (75 cm)
Material Package

Double Easy-Open bag
Material Size

1
Maximum Differential Pressure

80 psi (5.5 bar) continuous100 psi (6.9 bar) intermittent
Maximum Differential Pressure, bar (psid)

Forward: 6.9 bar (100 psid) intermittent @ 25 °C; 5.5 bar (80 psid) @ 25 °C; 1.0 bar (15 psid) @ 80 °C. Reverse: 2.1 bar (30 psid) @ 25 °C, intermittent
Maximum Inlet Pressure (psig)

80 psig
Maximum Inlet Pressure, bar (psi)

6.9 bar (100 psi) intermittent @ 25 °C; 5.5 bar (80 psi) @ 25 °C; 2.75 bar (40 psi) @ 60 °C; 1.0 bar (15 psi) @ 80 °C
Maximum Inlet Temperature

25 °C
Media

Millipore Express® SHF
Non-Fiber Releasing

This product was manufactured with a Millipore Express® membrane which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
Outlet Connection

Hose Barb
Outlet Connection Diameter

5/8 in.
Oxidizable Substances

Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥3 L
Pore Size

0.2 µm
Seal Material

Silicone (SI)
Sterilization

3 autoclave cycles of 60 min @ 126 °C; not in-line steam sterilizable
Support Material

Polypropylene
Trade Name

Millipore Express®
USP Bacterial Endotoxins

A sample aqueous extraction contains less than 0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) test.
Vent Cap Material

Polypropylene (PP)
Wettability

Hydrophilic
Width

19.8 cm (7.8 in.)

DESCRIPTION

Genuine product
