: Catalog No. P2B100C01

Part No. P2B100C01
Supplier Merck KGaA

Pellicon® 2 Mini Cassette with Biomax® 100 kDa Membrane, C screen, 0.1 m²

Net Price

USD 844

Availability

4 weeks

PROPERTIES

Catalogue Number

P2B100C01
Chemistry

Polyethersulfone (PES)
Device Configuration

Mini Cassette
Device Material

Polypropylene
Filter Code

Biomax 100
Filter Type

Ultrafiltration
Good Manufacturing Practices

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Gravimetric Extractables

The extractables level was equal to or less than 1500 mg/m² after a water flush.
Height

1.5 cm (0.6 in.)
Key Applications

Protein PurificationAnalytical Sample Prep
Length

20.6 cm (8.1 in)
Material Size

1
Maximum Operating Temperature

0 - 50°C
Maximum Transmembrane Pressure

Forward: 6.8 bar (100 psig) @ 30°C; Reverse: 0.3 bar (5 psig) maximum
Media

Biomax®
Membrane Area

0.1 m²
NMWL

100 kDa
pH Range

pH1 – pH14
Recirculation Rate

4 to 7 L/min/m²
Screen Material

Polypropylene (PP)
Screen Type

Type C screen (coarse screen)
Trade Name

Pellicon®
Width

5.6 cm (2.2 in.)
