Bacterial Endotoxins
Aqueous extraction contains ≤0.5 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
-
Bacterial Retention
Samples were quantitatively retentive of a minimum Brevundimonas diminuta challenge concentration of 1 x 10⁷ CFU/cm² using ASTM® F838 methodology.
-
Cartridge Code
Not Applicable
-
Cartridge Nominal Length
4 in. (10 cm)
-
Catalogue Number
LCGL04TP6
-
Chemistry
Polyvinylidene Fluoride (PVDF)
-
Device Configuration
Cartridge
-
Device Material
Polypropylene
-
Device Size
4 in.
-
Filtration Area
0.18 m²
-
Flow Rate
15 L/min @ 850 mbar ΔP
-
Good Manufacturing Practices
These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
-
Gravimetric Extractables
The extractables level was equal to or less than 10 mg per 4-inch cartridge after 24 hours in water at controlled room temperature.
-
Length
4 in. (10 cm)
-
Material Package
Double Easy-Open bag
-
Material Size
6
-
Maximum Differential Pressure, bar (psid)
Forward: 5.5 bar (80 psid) @ 25 °C; 3.5 bar (50 psid) @ 80 °C; 0.35 bar (5 psid) @ 121 °C. Reverse: 3.5 bar (50 psid) @ 25 °C KEEP
-
Maximum Inlet Pressure, bar (psi)
Forward - 5.5 bar (80 psi) @ 25 °C; 3.5 bar (50 psi) @ 80 °C; 0.35 bar (5 psi) @ 121 °C; Reverse - 3.5 bar (50 psi) @ 25 °C
-
Media
Charged Durapore®
-
Non-Fiber Releasing
This product was manufactured with a Durapore® membrane which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
-
Oxidizable Substances
Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥500 mL
-
Pore Size
0.22 µm
-
Seal Material
Silicone (SI)
-
Sterility
Other
-
Sterilization
10 SIP cycles of 30 min @ 135 °C
-
Support Material
Polypropylene
-
Trade Name
Optiseal®
-
USP Bacterial Endotoxins
A sample aqueous extraction contains less than 0.5 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) test.
-
Wettability
Hydrophilic
