Bacterial Retention
Samples of the Durapore® membrane used in this cartridge were quantitatively retentive of a minimum Brevundimonas diminuta challenge concentration of 1 x 10⁷ CFU/cm² using ASTM® F838 methodology.
-
Cartridge Code
Code 7 (2-226) O-rings w/locking-tabs
-
Cartridge Nominal Length
30 in. (75 cm)
-
Catalogue Number
CVDI73TPE
-
Chemistry
Polyvinylidene Fluoride (PVDF)
-
Device Configuration
Cartridge
-
Device Material
Polypropylene
-
Device Size
30 in.
-
Diameter
6.9 cm (2.7 in.)
-
Filtration Area
2.07 m²
-
Good Manufacturing Practices
These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
-
Gravimetric Extractables
The extractables level was equal to or less than 25 mg per 10-inch cartridge after 24 hours in water at controlled room temperature.
-
Indirect Food Additive
All component materials meet the FDA Indirect Food Additive requirements cited in 21 CFR 177-182. All component materials meet the requirements of the EU framework regulation [1935/2004/EC] regarding materials and articles intended to contact food.
-
Length
30 in. (75 cm)
-
Material Size
1
-
Maximum Differential Pressure, bar (psid)
Forward: 5.5 bar (80 psid) @ 25 °C; 1.7 bar (25 psid) @ 80 °C; 0.35 bar (5 psid) @ 135 °C. Reverse: 3.5 bar (50 psid) @ 25 °C, intermittent
-
Media
Durapore®
-
Non-Fiber Releasing
This product was manufactured with a Durapore® membrane which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
-
Pore Size
0.2 µm
-
Seal Material
Fluorocarbon rubber
-
Sterility
Other
-
Support Material
Polypropylene
-
Trade Name
Durapore®
-
Wettability
Hydrophilic
