KTGRA05FF1 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. KTGRA05FF1

Part No. KTGRA05FF1
Supplier Merck KGaA

Aervent KTGR Opticap XL5 Capsule

Net Price

316

Availability

4 weeks

PROPERTIES

Bacterial Endotoxins

Aqueous extraction contains <0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Bacterial Retention

Samples were quantitatively retentive of a minimum Brevundimonas diminuta challenge concentration of 1 x 10⁷ CFU/cm² using ASTM® F838 methodology.
Cartridge Nominal Length

5 in. (13 cm)
Catalogue Number

KTGRA05FF1
Chemistry

Polytetrafluoroethylene (PTFE)
Device Configuration

Capsule
Device Material

Polypropylene
Device Size

5 in.
Diameter

10.7 cm (4.2 in.)
European Pressure Equipment Directive

EMD Millipore Corporation® certifies that this product complies with the European Pressure Equipment Directive, 97/23/EC of 29 May 1997. This product has been classified under Article 3 § 3 of the Pressure Vessel Directive. It has been designed and manufactured in accordance with sound engineering practice to ensure safe use. In compliance with Article 3 § 3 of this Pressure Vessel Directive, this product does not bear the CE mark.
Filtration Area

0.32 m²
Gravimetric Extractables

The extractables level was equal to or less than 28 mg per 10-inch cartridge after 24 hours in a 70/30% IPA/water mixture at controlled room temperature.
Housing Material

Polypropylene (PP)
Inlet Connection

Sanitary Flange
Inlet Connection Diameter

3/4 in.
Inlet to Outlet Width

21.0 cm (8.3 in.)
Length

5 in. (13 cm)
Material Package

Double Easy-Open bag
Material Size

1
Maximum Differential Pressure, bar (psid)

Forward: 5.5 bar (80 psid) @ 25 °C; 1.0 bar (15 psid) @ 80 °C. Reverse: 4.1 bar (60 psid), intermittent
Maximum Inlet Pressure (psig)

80 psig
Maximum Inlet Pressure, bar (psi)

Forward - 5.5 bar (80 psi) @ 25 °C; 2.8 bar (40 psi) @ 60 °C; 1.0 bar (15 psi) @ 80 °C; Reverse - 4.1 bar (60 psi), Intermittent
Maximum Inlet Temperature

25 °C
Media

Aervent®
Non-Fiber Releasing

This product was manufactured with a PTFE membrane which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
Outlet Connection

Sanitary Flange
Outlet Connection Diameter

3/4 in.
Pore Size

0.2 µm
Seal Material

Silicone (SI)
Sterilization

30 autoclave cycles of 30 min @ 135 °C
Support Material

Polypropylene
Trade Name

Aervent®
USP Bacterial Endotoxins

Aqueous extraction contains <0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Vent Cap Material

Polypropylene (PP)
Wettability

Hydrophobic
Width

21.0 cm (8.3 in.)

DESCRIPTION

Genuine product
