The Hydrosol filter holder is designed for the filtration of flammable liquids. Unlike other filter holders, the Hydrosol filter holder includes a grounding unit to prevent sparking from static discharge, which can be a safety hazard. Applications:Vacuum Filtration of Flammable Liquids XX2004720 Hydrosol Filter Holder, 47 mm, stainless steelReplacement PartsXX2004704 Funnel and Locking Ring Assembly, stainless steelXX2004708 Support Screen, 47 mm, stainless steelXX2004702 Base with Screen, gasket and supportXX2004703 Gasket, PTFE XX2004718 No. 8 Stopper, 9.5 mm (3/8 in.) hole, siliconeXX20047RK Replacement Parts Kit for Hydrosol Filter Holder AccessoriesXX1004705 Vacuum Filtering Flask, 1 LXX1004744 Vacuum Filtering Flask, 4LXX7100004 Tubing 3/16 in. I.D. x 140 cm, siliconeXX6200006P Filter Forceps, blunt end, stainless steelXX2604735 3-place Manifold, 47 mm, PVCXX2504735 3-place Manifold, 47 mm, stainless steelXX2504700 6-place Manifold, 47 mm, stainless steelWP6211560 High Output Pump, 115 V/60 HzWP6222050 High Output Pump, 220 V/50 HzWP6210060 High Output Pump, 100 V/50-60 Hz
Catalogue Number
XX2004720
Diameter
11.4 cm
Filter Diameter (⌀)
47 mm
Filtration Area
9.6 cm²
Fitting Inlet
Funnel
Fitting Outlet
No. 8 perforated silicone stopper mounts in standard 1 L filtering flask
Funnel Capacity
650 mL
Height
22.9 cm
Material Size
1
Materials of Construction
Stainless steel funnel, base and filter support screen; anodized aluminum locking ring; nylon lockwheels; silicone stopper
